The MRV SII 04 HP Inverter Outdoor Unit – Hot & Cold is built for advanced, high-efficiency performance across all weather conditions. Equipped with a DC inverter rotary compressor, it delivers powerful cooling and heating with exceptional energy savings. The unit supports up to 8 indoor units, offers wide installation flexibility with long piping distances, and ensures stable operation through its strong airflow, high static pressure, and intelligent capacity management. Designed for durability and super comfort, this outdoor unit is ideal for modern commercial and residential MRV systems.
| Technical Specification: MRV SII 04 HP Inverter Outdoor Unit – Hot & Cold | |
|---|---|
| Basic Info | |
| Capacity | 04 HP |
| Product Segment | MRV Outdoor |
| Price | ₹2,49,000 |
| Technology | Inverter AC |
| Cooling & Heating Performance | |
| Cooling Capacity (kW) | 12.1 |
| Heating Capacity (kW) | 14.2 |
| Cooling Capacity (KBtu/hr) | 41.29 |
| Heating Capacity (KBtu/hr) | 48.5 |
| Power Supply | 3-Ph / 380~415V / 50Hz |
| Air Flow | 7200 m³/hr |
| Sound Pressure Level (Cooling – H) | 57 dB(A) |
| Sound Pressure Level (Heating – H) | 57 dB(A) |
| External Static Pressure | 110 Pa |
| Dimensions & Weight | |
| External Dimensions (W × D × H) | 950 × 370 × 1340 mm |
| Net Weight | 108 kg |
| Compressor | |
| Compressor Type | Rotary |
| Compressor Qty. | 1 – DC Inverter |
| Refrigerant | R-410A |
| Piping Details | |
| Piping Connection – Liquid | Ф9.52 |
| Piping Connection – Gas | Ф15.88 |
| Max. Total Pipe Length | 300 m |
| Max. Pipe Length (Equivalent / Actual) | 175 m / 150 m |
| Max. Elevation Difference (O.D.U Down / Up) | 50 m |
| Max. Drop Between Indoor Units | 15 m |
| Diversity | 50% ~ 130% |
| Max. Number of Indoor Units | 8 |
| Operating Temperature Range | |
| Cooling Only | -5°C ~ 50°C |
| Hot & Cold Mode | -20°C ~ 27°C |
